Automatic Cartoning Machine for Tea Bag/Milk bag/Coffee bag

Model: JDZ-100
Place of Origin: Zhejiang,China (Mainland)
Processing: Packing Machine
Automatic Grade: Automatic
Type: General
Usage: Outer
Packaging: Metal
Brand Name: Jiade
Machine function: inser product and leaflet into the carton automatically
  video

inquiry

skype basketAdd to Basket  Edit

Share |

Product Description

Payment & Shipping Terms Supply Capacity
Unit Price:31000.0 USDProduction Capacity:20sets/month
Trade Term:FOB,CFR,CIFPacking:with wooden case
Payment Terms:L/C, T/TDelivery Date:45 days
Min. Order:1 Set/Sets
Means of Transport:Land, Ocean, Air

Instruction

cartoning machine is suitable for blister ,bottle, pouchs and

injection,medicine,cosmetis,condom.food.,tube,ointment,wrapped products.The machine finished running by a series of photo-electro controller to make the machine stability and guarantee the packing quality. It includes 1to 4folds leaflet automatic folding, cantons in suction and open, products and leaflet put into, printing batch number, sealing or option hot-glue device. The machine can be single used or linked with Filling Machine, Blister Packing Machine, Shrink Machine, Three Dimensional Packaging Machine to form a production chain.

Feature

1.International famous brand of electrical component such as PLC touch screen, frequency inverters, etc.

2.Adopt human-machine operation system.

3.Automatically displaying device for trouble, speed and finished products counting.

4.Machine running without pressing if no products or incorrect position of products. And stopping automatically if incorrect position of product into carton after return or no cartons or out of leaflets continuous.

5.No products not suction leaflet, no leaflet not suction carton .

6.Automatic detection and rejection device for lacking blister goods and leaflets.

7.Protecting automatically for overloading.

8.stable performance , operation is easy .

Main technical parameters

Encasing speed

30-100 boxes/min

Box

Quality requirement

250-350g/m2

Dimension rangeL×W×H

(70-180)mm×(35-85)mm×(14-50)mm

Quality requirement

60-70g/m2

Leaflet

Unfolded leaflet specificationL×W

(80-250)mm×(90-170)mm

Fold range

(1-4) fold

Compressed air

Working pressure

0.6mpa

Air consumption

120-160L/min

Power

220V/50Hz

Motor power

0.75kw

Machine dimension(L×W×H)

3100mm×1100mm×1550mm

Machine weight

1400kg

Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
Automatic Cartoning Machine for tea bag/milk bag/coffee bag
